Case study

ROAMES® optimised management - substation retrofit

The Netherlands

Stock images for Fugro.com

Client

Alliander/Liandon

When the French Ministry of Defence identified a location for the new command centre for its army, one of the first requirements was an unexploded ordnance safety diagnosis. Historical studies of the site in Paris suggested the possibility of unexploded bombs following allied forces bombardments in 1943.

Life cycle

Planning, feasibility, conceptual design

Design

Construction

Operations and maintenance

Decommissioning

Show full process

Traditionally, inventory work for a substation retrofit project entails finding and collating historical information, conducting multiple site visits and designing on a diverse base from unknown sources. With work in and around substations becoming more frequent, Alliander wanted to find a way to undertake these projects more effectively, to save time and money and reduce staff exposure to on-site risks.

We implemented our ROAMES® service, which provided Liandon with a direct solution to enable the owner and operator to manage and utilise all collected field data and to streamline their substation operations via a simple web-based service.

In just one day, Fugro surveyed the full 150 kV Rilland station using state-of-the-art 3D terrestrial laser scanners. This rapid and highly accurate (engineering grade) survey technology scans the entire substation. In contrast to the conventional delivery of survey (point cloud) data, we build an accurate 3D virtual model of the substation, creating a turnkey end product that can be viewed in Fugro’s SITE-SPOT® interactive web environment.

This delivered a direct cost reduction in design and retrofit effort and formed the base for future digital asset management of the substation.

The SITE-SPOT® application has been positively received by Alliander, Liandon and external contractors. The ability to view the data remotely has significantly reduced the number of site visits during the reconstruction. This is not only more cost-efficient but also has clear health and safety benefits because it reduces staff exposure to working around live, high-voltage equipment and other on-site risks.

Paul van der Horst

Technical Manager, Liandon

Existing news images for Fugro.com (2023)

Used technology

Fugro ROAMES®

Fugro ROAMES®

Fugro Roames® delivers a powerful 3D real-world environment of your powerline network, enabling you to asses, monitor and maintain your network effectively and efficiently to optimise powerline performance and reduce risk.

Key benefits

  • 3D virtual model of a substation that can be accessed via a simple web-based service

  • No necessity for new software, plug-ins or training

  • Sites can be assessed from the office saving costs and reducing on-site risks

  • Engineers can toggle between 2D and 3D views, and can measure, attach notes and extract information on all components of the substation

  • Aggregated survey data is available as a single point-of-truth archive for future asset management predictions.

The use of SITE-SPOT® has significantly reduced the number of site visits during the reconstruction of the Rilland substation
